Description:

20 Series models offer additional comfort and convenience features: tilt steering wheel, loader joystick on the fender, cruise control, metal floorboard with rubber mat, and phone charger.

Features:

• Power and Performance
• Fuel-efficient KIOTI 3-cylinder diesel engine with smooth-shifting hydrostatic transmission for optimal control. Standard differential lock ensures traction, while rear and mid PTOs and a category I 3-point hitch lets you attach a variety of implements with ease.
• Hydrostatic Transmission
• Infinite 2-range hydrostatic transmission for effortless control, twin pedals for intuitive forward and reverse movements, seamlessly adjusting speed without ever touching a clutch.
• Streamlined Hood Design
• Single-lever engaged 4WD is standard on the CS2210 tractor.
• Ergonomic Operator Station
• The ergonomically designed workstation places operator controls within easy reach for maximum comfort.
• Foldable ROPS
• The standard fold-down roll bar allows you to move into low clearance areas quickly and easily.
• Headlights
• 55W lamps are the brightest in this tractor's class.
• Control Levers
• The HST with HI-LO range lever allows the tractor to overcome a wide range of load tasks. The rear PTO and mid PTO can be controlled separately or together with a simple in-line shifting lever. The height adjustment lever allows the operator to easily control the mid-mount mower grass cutting height.
• Four Wheel Drive
• Single-lever engaged 4WD is standard on the CS2210 tractor.
• Twin HST Pedals
• Twin HST pedals offer easy forward and reverse movement with smooth engagement, acceleration and deceleration. Pedal pressure is minimized which reduces operator fatigue during long hours of use.
• Mid PTO
• The standard mid PTO (2,200 rpm) allows you to use implements such as a mid-mount mower.
• Illuminated Dashboard
• The dashboard illuminates when the engine is started. The digital gauge package includes tachometer, fuel and temperature gauges along with a low fuel warning lamp.

Specification:

Engine:

• Model: 3C100LFH-U2
• Manufacturer: KIOTI
• Power: 24.50 hp (18.30 kW)
• Displacement: 61.50 cu. in. (1,007 cc)
• RPM: 3,000 rpm
• Fuel Type: Diesel
• Aspiration: Intercooler
• Fuel Capacity: 6.70 gal (25.50 L)

Transmission:

• Type: Hydrostatic Shuttle
• Main Gear: Hydrostatic
• Travel Speeds Forward: 9
• Travel Speeds Reverse: 6
• Minimum Speed: 0 mph (0 km/h)
• Maximum Speed Forward: 9.57 mph (15.40 km/h)
• Minimum Speed Reverse: 0 mph (0 km/h)
• Maximum Speed Reverse: 6.60 mph (10.60 km/h)

PTO:

• Type: Independent
• Power: 18.50 hp (13.90 kW)
• Rear Speed: 540 rpm
• Mid Speed: 2,200 rpm

Drive Train:

• Brakes: Wet Multi Disc
• Clutch: Wet Multi Disc
• Steering: Hydraulic Power Steering

Hydraulics:

• Pump Type: Gear
• Pump Capacity: 7 gpm (26.40 lpm)
• Lift Capacity: 700 lb (318 kg)

Hitch:

• Type: Three Point
• Category: Category 1
• Control Type: Position
• Lift Capacity: 1,500 lb (680 kg)

Dimensions:

• Length with Hitch: 99.30 in (2,523 mm)
• Width: 45.90 in (1,168 mm)
• Wheelbase: 55.10 in (1,400 mm)
• Ground Clearance: 6.40 in (162 mm)
• Front Tread: 44.60 in (1,133 mm)
• Rear Tread: 46 in (1,168 mm)
• Turning Radius: 8.20 ft (2.54 m)
• Height: 88 in (2,226 mm)
• Weight: 1,554 lb (705 kg)
