Description:

With a weatherproof factory cab, the K9 2400 Cab lets you conquer any terrain, any season. No more battling rain, wind, or sun.

Specifications:

Engine

• Engine Model: 3C100LFU-U3
• Engine Manufacturer: KIOTI
• Engine Power: 24 hp (18.30 kW)
• Engine Displacement: 61.50 cu. in. (1,007 cc)
• Engine RPM: 3,200 rpm
• Engine Fuel Type: Diesel
• Engine Aspiration: Intercular
• Fuel Capacity: 9.80 gal (37 L)

Drive Train

• Drive Train Model: Belt CVT
• Drive Train Brakes: Front/Rear Hydraulic Disc
• Drive Train Gears: Low, High, Neutral, Reverse
• Travel Speed (Min): 0 mph (0 km/h)
• Travel Speed (Max): 31 mph (50 km/h)

Suspension & Steering

• Front Suspension: Independent, Double A-Arm (Wishbone type)
• Rear Suspension: Independent, Double A-Arm (Wishbone type)
• Steering: Hydraulic Power Steering

Dimensions & Capacities

• Length: 119.80 in (3,045 mm)
• Width: 65.60 in (1,640 mm)
• Height: 78.40 in (1,990 mm)
• Wheelbase: 85.80 in (2,180 mm)
• Weight: 2,215 lb (1,050 kg)
• Ground Clearance: 12.50 in (318 mm)
• Turning Radius: 15.10 ft (4.60 m)

Cargo & Towing

• Towing Capacity: 1,300 lb (590 kg)
• Payload Capacity: 1,750 lb (794 kg)
• Cargo Bed Dimensions:
• Length: 43.70 in (1,110 mm)
• Width: 58.20 in (1,480 mm)
• Depth: 11.50 in (293 mm)
• Cargo Capacity: 1,102 lb (500 kg)
