Description:

Revolutionize your land management experience with the industry's first sub-compact tractor to come equipped with a fully contented, 4-season comfort, factory-installed cab with heat and air.

Specifications:

Engine

• Model: 3L123
• Manufacturer: KIOTI
• Power: 24.50 hp (18.30 kW)
• Displacement: 75.20 cu. in. (1,233 cc)
• Fuel Type: Diesel
• Aspiration: Intercooler
• Fuel Capacity: 6.60 gal (25.50 L)
• Rated RPM: Not specified

Transmission

• Type: Hydrostatic
• Shuttle: Hydrostatic
• Main Gear: 2-Range
• Travel Speeds (Forward): Infinite
• Travel Speeds (Reverse): Infinite
• Min Forward Speed: 0 mph (0 km/h)
• Max Forward Speed: 8.99 mph (14.47 km/h)
• Min Reverse Speed: 0 mph (0 km/h)
• Max Reverse Speed: 6.15 mph (9.90 km/h)

PTO (Power Take-Off)

• Type: Independent
• PTO Power: 19.30 hp (14.40 kW)
• Rear PTO Speed: 540 rpm
• Mid PTO Speed: 2,200 rpm

Drive Train

• Brakes: Wet Multi Disc
• Clutch: None
• Steering: Hydraulic Power Steering

Hydraulics

• Type: Open Center
• Pump Capacity: 7 gpm (26.40 lpm)
• Lift Capacity: 700 lb (317 kg)

3-Point Hitch

• Type: Three Point
• Category: Category 1
• Control Type: Position
• Lift Capacity: 700 lb (318 kg)

Dimensions & Weight

• Length with Hitch: 102.90 in (2,613.70 mm)
• Height: 82.60 in (2,098.04 mm)
• Width: 48.30 in (1,226.82 mm)
• Ground Clearance: 6.40 in (162 mm)
• Front Tread: 44.60 in (1,132.84 mm)
• Rear Tread: 48.30 in (1,226.82 mm)
• Turning Radius: 8.20 ft (2.54 m)
• Weight: 2,233.30 lb (1,013.01 kg)
